ISO 7816 SIM Card Reader
Hardware-in-the-loop SIM card analysis and sniffing
Overview
Custom hardware and firmware solution for intercepting and analysing SIM card communication. Built on the Raspberry Pi Pico 2 (RP2350) platform, this project captures the half-duplex ISO 7816 protocol traffic between a cellular modem and its SIM card.
Technical Details
- ISO 7816 protocol decoding — T=0 character-level communication captured and parsed in real time
- RP2350 firmware — bare-metal C using the Pico SDK, with UART-based stdio for debugging
- Half-duplex handling — the single-wire ISO 7816 I/O line requires careful timing and direction sensing
- Watchdog-protected — 5-second hardware watchdog with crash-state tracking in noinit RAM for reliable long-duration captures
- Logic analyzer integration — captured traces validated against Saleae logic analyzer for correctness
Outcome
Successfully captured and decoded live SIM-modem communication, revealing ATR sequences, file system reads, and authentication exchanges. The tool provides visibility into a normally opaque communication channel, useful for debugging eSIM profile switching and modem-SIM interaction issues.
